產品說明 LED street light –60W
Item: 508-SL-3600
Description: Street Light
consumptio Power (W): 60W
light source :1.2W *50 PCS
(Lm)Rated net luminous output from luminaire (Lm): 3600
(Lm)Total Luminous Flux on Roadway (Lm): 2500
Pole height: 4-8M
Illuminance(Central) 6M height: 35 Lux for 6m High
(Lux)Illuminance from 8m High on Roadway (Lux): 25 Lux for 8m High
Color Temperature: 4500-5500K
Housing: Aluminum with Painting
Base type: IP65 Connector or Connector Free
Outer Dimension: 485mm x 185mm x 130mm
Housing Color: Silver
Weight: Power Requirement: Transformer constant 24VDC output for Lighting Module
Power Consumption: 1.2W for each emitter; 50PCS emitters are used,Above 90% Efficiency for LED driver board,~85% Efficiency for Transformer from 110VAC to 24VDC
Beam Angle: X (Direction follow the road): 100 degree,Y (Direction cross the road): 60degre
IP Level: IP66
LED Life: > 50,000hrs
