產品說明 ZTW Spider 12A OPTO ESC - ZTW5012301
ZTW Spider OPTO ESCs are quality speed controllers and designed for simple installation and easy setup. These ESCs have proven to offer excellent performance in Multi-rotor applications. If you are starting out in Multi-rotors and need an easy-to-install solution that is tested and proven to work with Multi-rotor craft then these speed controllers have you covered. The ZTW Spider 12A OPTO ESC features a very smooth yet linear throttle response, without sacrificing a rapid, crisp, response to any throttle input. Super fast Refresh Rate up to 600Hz make these a very smooth controller.

FEATURES:

Extremely low internal resistance
Super smooth and accurate throttle linearity
Safety thermal over-load protection
Auto throttle shut down in signal loss situations
Supports high RPM motors
Power arming protection
Use new generation of the MOSFETs
REQUIRES:

Direct connection to motor or bullet connectors
Battery connector
NOTES:

This 12A ESC has bare leads only.

PRODUCT SPECIFICATIONS:

Length
26mm / 1.02in
Width
15mm / 0.59in
Height
6mm / 0.23in
Weight
8g
MAX Output
Continuous Current 12A
Burst Output
20A
Battery
5-18NC/2-4Lipo
BEC Output
5.0V 6.0V 7.4V 8.4V Adjustable/8A
Power Connector
Bare Leads
Motor Connector
Bare Leads
