Network dual light dot matrix camera home security system

產品說明 Introduction:HA-8403 is integrating the traditional camera and network video server embedded into an digital monitoring system.
Based on an embedded Linux Operation system. And adopts Hi3518C hardware platform with high efficient and low volume. high performance, good stability and reliability.
With DHCP Way, P2P Cloud Store, Alarm Security Functions.
It can work with ip alarm system such as ST-VGT which supports 32 IP Cameras.
32 Wireless Alarm Devices (door sensor, remotes, pir motion detectors......)
All Alarm devices can bind each 32 IPCams to alarm.


Users can receive the alarming from app, auto recording the video from app after alarming.
Freely to check all the alarming events recording, even from TF card.

Operation system: Embedded Linux
User interface: IE browser, CMS PC client, phone application
Video format: mainstream 720P/D1 25fps, Sub-stream D1/CIF 25fps
Network interface: 10M/100M adaptive network interface
Storage interface: TF card,support max 128G(1st time, please format TF card on IE browser
interface).Use a hex screwdriver to open the cover to see the TF card slot.
Image sensor: Crystal phase H62,100W (1280*720)
Power: DC 12V/1A

Specification:
camera lens type: 1/2.9 "CMOS
Resolution: 2MP(1920*1080)
Number of infrared red lights: 2PCS
Infrared distance: 20m
Lens focal length: 3.6mm
Field Angle: H58°; V53 °
Audio format: G711A
image compression: H.265
Video Frame rate: 1920×1080 25 frames/second
Video mode: multi-image intelligent alarm video
storage mode:<=128G SD card, cloud storage
Voice intercom: Two-way voice intercom, remote monitoring
Network interface: 10Mbps/100Mbps adaptive RJ45 interface
Network protocols: TCP/IP, HTTP
Wi-Fi Relay: Supported
Wi-Fi protocol: IEEE802.11b/g/n
IP address support: static IP address, dynamic IP address
Intelligent analysis: with human recognition and warning function
Day/night mode: double filters automatically switch to IR-cut day/night
Support mobile APP video monitoring and remote control
Alarm notification: FTP upload pictures and videos, SMS alarm notification, etc
(Server required)
Support P2P/IE control/platform /Onvif protocol
Wifi support, support audio configuration
With PW-12V-1A power adaptor
DC interface, 12V 1A power supply
Case: Metal case, waterproof grade IP65, suitable for indoor and outdoor.
Waterproof rating: IP65
Size: 118 * 70 * 63 mm

產品規格 User interface: IE browser, CMS PC client, phone application Video format: mainstream 720P/D1 25fps, Sub-stream D1/CIF 25fps Network interface: 10M/100M adaptive network interface
