SOLAR POWERED 4 BEAMS WIRELESS INFRARED GRATING

This is solar-powered product and should be installed at place where sunlight intensity more than 2200lux.
Functions and Specification:
1.It is four beams wireless outdoor infrared grating working by pairs of transmitter and receiver.
2.Irradiation distance:6m
3.Wireless Transmitting distance: 100m
4.Wireless frequency:433MHz
5.Maximum alarm times in 24 hours:<=50 times
6.Battery capacity: transmitting terminal: 500mA, receiving terminal: 500mA
7.Working temperature: -30℃~70℃
8.Number of infrared beams: 4 beams
9.Working voltage:3.3V
10.Power storage type: LiFePO4 Battery
11.Static working current: transmitting terminal<=0.6mA, receiving terminal<=0.6mA
13.Infrared light frequency: secondary modulation & encoding based on 38KHz
14.Infrared light wave-length: 940nm+/-20nm
15.Output current of solar panel: Under the condition of 1600Lux lighting >=1.5mA (Outdoor illumination in ordinary rainy or cloudy days is about 2000Lux)
16.Dimension:620*48*56mm
17.Distance between two infrared light hole: 164mm between 1st group and 2nd group. 86mm between two holes in same group.

CE

Solar Powered Wireless installation, converter equipped for alarm compatibility Solar Powered Wireless installation, converter equipped for alarm compatibility
